torc::bitstream::Spartan6Bitstream Class Reference
Spartan-class bitstream. More...
#include <Spartan6Bitstream.hpp>
Public Member Functions | |
| Spartan6Bitstream (void) | |
| Basic constructor. | |
| virtual void | readPackets (std::istream &inStream) |
| Read bitstream packets from a stream. | |
| virtual void | writePackets (std::ostream &inStream) |
| Write bitstream packets to a stream. | |
| virtual void | preflightPackets (void) |
| Preflight the packets. | |
| virtual void | updatePacketLength (void) |
| Update the header packet length. | |
Protected Types | |
| typedef boost::uint16_t | uint16_t |
| Imported type name. | |
| typedef boost::uint32_t | uint32_t |
| Imported type name. | |
Friends | |
| class | torc::bitstream::bitstream::Spartan6BitstreamUnitTest |
Detailed Description
Spartan-class bitstream.Definition at line 32 of file Spartan6Bitstream.hpp.
Member Typedef Documentation
typedef boost::uint16_t torc::bitstream::Spartan6Bitstream::uint16_t [protected] |
Imported type name.
Reimplemented from torc::bitstream::Bitstream.
Reimplemented in torc::bitstream::Spartan6.
Definition at line 38 of file Spartan6Bitstream.hpp.
typedef boost::uint32_t torc::bitstream::Spartan6Bitstream::uint32_t [protected] |
Imported type name.
Reimplemented from torc::bitstream::Bitstream.
Reimplemented in torc::bitstream::Spartan6.
Definition at line 39 of file Spartan6Bitstream.hpp.
Constructor & Destructor Documentation
| torc::bitstream::Spartan6Bitstream::Spartan6Bitstream | ( | void | ) | [inline] |
Member Function Documentation
| void torc::bitstream::Spartan6Bitstream::readPackets | ( | std::istream & | inStream | ) | [virtual] |
Read bitstream packets from a stream.
- Note:
- This function should be called after the bitstream header has been read.
Reimplemented from torc::bitstream::Bitstream.
Definition at line 23 of file Spartan6Bitstream.cpp.
| void torc::bitstream::Spartan6Bitstream::writePackets | ( | std::ostream & | inStream | ) | [virtual] |
Write bitstream packets to a stream.
Reimplemented from torc::bitstream::Bitstream.
Definition at line 32 of file Spartan6Bitstream.cpp.
| void torc::bitstream::Spartan6Bitstream::preflightPackets | ( | void | ) | [virtual] |
Preflight the packets.
Reimplemented from torc::bitstream::Bitstream.
Definition at line 38 of file Spartan6Bitstream.cpp.
| void torc::bitstream::Spartan6Bitstream::updatePacketLength | ( | void | ) | [virtual] |
Update the header packet length.
Reimplemented from torc::bitstream::Bitstream.
Definition at line 94 of file Spartan6Bitstream.cpp.
The documentation for this class was generated from the following files:
- torc/bitstream/Spartan6Bitstream.hpp
- torc/bitstream/Spartan6Bitstream.cpp
