torc::generic::Cell Class Reference
Represents an EDIF cell. More...
#include <Cell.hpp>
Public Types | |
| enum | Type { eTypeTie = 0, eTypeRipper, eTypeGeneric } |
| typedef VisitorType< Cell > | Visitor |
Public Member Functions | |
| virtual void | accept (BaseVisitor &inoutVisitor) throw (Error) |
| const Type | getType () const throw () |
| void | setType (const Type &inSource) throw () |
| void | addView (const ViewSharedPtr &inView) throw (Error) |
| ViewSharedPtr | findView (const std::string &inName) throw () |
| void | removeView (const std::string &inName) throw (Error) |
| void | getViews (std::vector< ViewSharedPtr > &outViews) const throw () |
| template<typename _Action> | |
| void | applyOnAllViews (const _Action &action) throw (Error) |
Private Member Functions | |
| Cell (const Cell &rhs) | |
| Cell & | operator= (const Cell &rhs) |
Private Attributes | |
|
SymTab< std::string, ViewSharedPtr > | mViewSymTab |
| Type | mType |
| ParameterMapSharedPtr | mParameters |
Friends | |
| class | FactoryType< Cell > |
Classes | |
| class | Factory |
Detailed Description
Represents an EDIF cell.The Cell class is used to implement an EDIF cell object. It contains the different views of a cell. A cell can be concrete or extern (black-box).
- Note:
- Currently parser performs semantic checks for GENERIC type only. Programattic creation may be achieved. However, a warning may be emitted when cell type is set to TIE or RIPPER.
Definition at line 57 of file Cell.hpp.
Member Typedef Documentation
| typedef VisitorType<Cell> torc::generic::Cell::Visitor |
Member Enumeration Documentation
Member Function Documentation
| void torc::generic::Cell::accept | ( | BaseVisitor & | inoutVisitor | ) | throw (Error) [virtual] |
Recive a inoutVisitor to this class. The visit method of the inoutVisitor is called and a reference to this object is passed as a parameter. It has to be noted however, that a dynamic_cast is performed inside this method. If the cast fails, an appropriate exception is thrown by this method. This sitation can arise when the passed Visitor object does not inherit from the appropriate inoutVisitor specialization. See Visitor documentation for more details.
- Parameters:
-
[in,out] inoutVisitor A reference to the inoutVisitor object
- Exceptions:
-
Error Visitor type inappropriate for visiting this object or any other error thrown by the Visitor::throw() method.
Implements torc::generic::Visitable.
| const Cell::Type torc::generic::Cell::getType | ( | void | ) | const throw () [inline] |
| void torc::generic::Cell::setType | ( | const Type & | inSource | ) | throw () |
| void torc::generic::Cell::addView | ( | const ViewSharedPtr & | inView | ) | throw (Error) |
Add a view to the list of views. An empty pointer will be ignored. If an view already exists in EDIF file in same cell, parser ignores the view.
- Parameters:
-
[in] inView Pointer to a view.
- Exceptions:
-
Error Empty View type - Id : eMessageIdErrorEmptyItemName
Error View name already exists - Id : eMessageIdErrorItemAlreadyExists
- Parameters:
-
[in] inView Pointer to a view.
| ViewSharedPtr torc::generic::Cell::findView | ( | const std::string & | inName | ) | throw () |
Find a view by name.
- Parameters:
-
[in] inName Name of the cell to be found.
- Returns:
- Pointer to cell if found, empty pointer otherwise.
- Parameters:
-
[in] inName Name of the cell to be found.
- Returns:
- Pointer to cell if found, empty pointer otherwise.
| void torc::generic::Cell::removeView | ( | const std::string & | inName | ) | throw (Error) |
Remove the specified pointer from the view. Empty pointer is ignored.
- Parameters:
-
[in] inName name of the object to be removed
- Parameters:
-
[in] inName name of object to be removed
| void torc::generic::Cell::getViews | ( | std::vector< ViewSharedPtr > & | outViews | ) | const throw () [inline] |
| void torc::generic::Cell::applyOnAllViews | ( | const _Action & | action | ) | throw (Error) [inline] |
The documentation for this class was generated from the following files:
