torc::architecture::segments_regression_test_helper Class Reference
Regression test class for segments consistency across all devices. More...
Public Member Functions | |
| segments_regression_test_helper (DDB &inDDB) | |
| Basic constructor. | |
| void | operator() (void) |
| Analyze segment expansion, and detect any tilewire conflicts. | |
| void | analyzeSegmentTilewire (const Tilewire &inTilewire) |
| Verifies and enforces segment ownership of the specified tilewire. | |
Static Public Member Functions | |
| static void | statistics (void) |
| Outputs statistics on segment expansion. | |
Private Types | |
| typedef xilinx::TileCount | TileCount |
| typedef xilinx::TileIndex | TileIndex |
| typedef xilinx::TileTypeIndex | TileTypeIndex |
| typedef xilinx::WireCount | WireCount |
| typedef xilinx::WireIndex | WireIndex |
| typedef Segments::SegmentReference | SegmentReference |
| typedef xilinx::CompactSegmentIndex | CompactSegmentIndex |
| typedef boost::uint64_t | uint64_t |
Private Attributes | |
| DDB & | mDDB |
| const Tiles & | mTiles |
| const Segments & | mSegments |
|
std::map< Tilewire, CompactSegmentIndex > | mUsage |
| const CompactSegmentIndex | cUsagePruned |
| const CompactSegmentIndex | cUsageUndefined |
| uint64_t | mTilewireCount |
| uint64_t | mTilewiresAnalyzed |
| uint64_t | mTilewiresPruned |
| uint64_t | mTilewiresUndefined |
| uint64_t | mTilewireMismatches |
Static Private Attributes | |
| static uint64_t | sTotalTilewireCount = 0 |
| Total number of tilewires visited. | |
| static uint64_t | sTotalTilewiresAnalyzed = 0 |
| Total number of tilewires analyzed (visited or expanded). | |
| static uint64_t | sTotalTilewiresPruned = 0 |
| Total number of tilewires pruned from the device (absent from XDLRC). | |
| static uint64_t | sTotalTilewiresUndefined = 0 |
| Total number of tilewires never defined (sanity check). | |
| static uint64_t | sTotalTilewireMismatches = 0 |
| Total number of tilewire mismatches (more than one segment contending for one tilewire). | |
Detailed Description
Regression test class for segments consistency across all devices.Definition at line 49 of file SegmentsRegressionTest.cpp.
Constructor & Destructor Documentation
| torc::architecture::segments_regression_test_helper::segments_regression_test_helper | ( | DDB & | inDDB | ) | [inline] |
Member Function Documentation
| static void torc::architecture::segments_regression_test_helper::statistics | ( | void | ) | [inline, static] |
| void torc::architecture::segments_regression_test_helper::operator() | ( | void | ) | [inline] |
Analyze segment expansion, and detect any tilewire conflicts.
Definition at line 102 of file SegmentsRegressionTest.cpp.
| void torc::architecture::segments_regression_test_helper::analyzeSegmentTilewire | ( | const Tilewire & | inTilewire | ) | [inline] |
Verifies and enforces segment ownership of the specified tilewire.
Definition at line 176 of file SegmentsRegressionTest.cpp.
Member Data Documentation
uint64_t torc::architecture::segments_regression_test_helper::sTotalTilewireCount = 0 [static, private] |
uint64_t torc::architecture::segments_regression_test_helper::sTotalTilewiresAnalyzed = 0 [static, private] |
Total number of tilewires analyzed (visited or expanded).
Definition at line 70 of file SegmentsRegressionTest.cpp.
uint64_t torc::architecture::segments_regression_test_helper::sTotalTilewiresPruned = 0 [static, private] |
Total number of tilewires pruned from the device (absent from XDLRC).
Definition at line 71 of file SegmentsRegressionTest.cpp.
uint64_t torc::architecture::segments_regression_test_helper::sTotalTilewiresUndefined = 0 [static, private] |
Total number of tilewires never defined (sanity check).
Definition at line 72 of file SegmentsRegressionTest.cpp.
uint64_t torc::architecture::segments_regression_test_helper::sTotalTilewireMismatches = 0 [static, private] |
Total number of tilewire mismatches (more than one segment contending for one tilewire).
Definition at line 73 of file SegmentsRegressionTest.cpp.
The documentation for this class was generated from the following file:
- torc/architecture/SegmentsRegressionTest.cpp
