torc::generic::VectorPortBitReference Class Reference

Represents a reference to a bit of a port. More...

#include <VectorPortBitReference.hpp>

Inheritance diagram for torc::generic::VectorPortBitReference:

[legend]

Collaboration diagram for torc::generic::VectorPortBitReference:

[legend]

List of all members.

Public Types
typedef FactoryType < VectorPortBitReference >	Factory
typedef VisitorType < VectorPortBitReference >	Visitor
Public Member Functions
virtual void	accept (BaseVisitor &inoutVisitor) throw (Error)
virtual Connection	connect (const NetSharedPtr &inNet) throw (Error)
virtual void	disconnect (const Connection &inConnection) throw (Error)
virtual void	getConnectedNets (std::vector< NetSharedPtr > &outNets, bool inSkipChildConnections=false) const throw (Error)

---

Detailed Description

Represents a reference to a bit of a port.

The VectorPortBitReference class represents a reference to a bit of an array port.

Definition at line 45 of file VectorPortBitReference.hpp.

---

Member Function Documentation

void torc::generic::VectorPortBitReference::accept

(

BaseVisitor &

inoutVisitor

)

throw (Error) [virtual]

Recive a inoutVisitor to this class. The visit method of the inoutVisitor is called and a reference to this object is passed as a parameter. It has to be noted however, that a dynamic_cast is performed inside this method. If the cast fails, an appropriate exception is thrown by this method. This sitation can arise when the passed Visitor object does not inherit from the appropriate inoutVisitor specialization. See Visitor documentation for more details.

Parameters:

[in,out]

inoutVisitor

A reference to the inoutVisitor object

Exceptions:

Error

Visitor type inappropriate for visiting this object or any other error thrown by the Visitor::throw() method.

Implements torc::generic::Visitable.

Definition at line 43 of file VectorPortBitReference.cpp.

Connectable::Connection torc::generic::VectorPortBitReference::connect

(

const NetSharedPtr &

inNet

)

throw (Error) [virtual]

Connect a Net to this object.

Note:

This metod can be overridden by derived classes. However, the method must call the on_connected() method after this. The sigConnected_ signal must also be invoked in the overriding method.

Parameters:

[in]

inNet

A pointer to the Net object that needs to be Connected

Returns:

A connection that has been established. This can be used later for disconnection.

Connect a Net to this object.

Note:

This metod can be overridden by derived classes. However, the method must call the on_connected() method after this. The sigConnected_ signal must also be invoked in the overriding method.

Parameters:

[in]

inNet

A pointer to the Net object that eeds to be Connected

Returns:

A connection that has been established. This can be used later for disconnection.

Implements torc::generic::Connectable.

Definition at line 58 of file VectorPortBitReference.cpp.

void torc::generic::VectorPortBitReference::getConnectedNets	(	std::vector< NetSharedPtr > &	outNets,
		bool	inSkipChildConnections = false
	)			const throw (Error) [virtual]

Get the vector of Nets that are Connected to the current object. The connected elements are appended to the given vector

Parameters:

[out]

outNets

A vector of Connected nets

Get the vector of Nets that are Connected to the current object. The connected elements are appended to the given vector

Returns:

A vector of Connected nets

Reimplemented from torc::generic::Connectable.

Definition at line 119 of file VectorPortBitReference.cpp.

---

The documentation for this class was generated from the following files:

• torc/generic/om/VectorPortBitReference.hpp
• torc/generic/om/VectorPortBitReference.cpp
